Cleaning Machine 108L Remove Scale and Rust Leak Proof Pulse Mold Waterway Cleaner

Name: Cleaning Machine 108L Remove Scale and Rust Leak Proof Pulse Mold Waterway Cleaner
SKU: LTT-S1(108L)
Price: 5360.00 USD
Availability: InStock

Reference price range$5,360.00 - $5,500.00

Built to specification

Request a project quote

Final pricing depends on the part, batch size and selected configuration. Share the cleaning target and the factory team will confirm a suitable system.

Tank capacityFrequencyPowerVoltageAutomationCustom options

Send requirements WhatsApp Email this product

SKU: LTT-S1(108L) Category: Special Ultrasonic Cleaners

Product overview

Specifications and product details

The complete original product information is kept below for technical review.

1. Adopt Mitsubishi PLC touch screen in 7 inches and Mitsubishi frequency changer.
2. Adopt Keenshi ultrasonic flow-meterand SMC booste pump.
3. Adopt Kaitz electronic pulse generator imported from Japan,Schneider switch, Ming Wei Power supply from Taiwan.
4. 4 in and 4 out, 8 in and 8 out, 1 group of wire in diameter 12MM fast interface.
5. 1 in and 1 out, 1 set of 1.5 inch inner wire connectors.

Description
Additional information

Description

Lush Trees Tech Cleaning Machine 108L Remove Scale and Rust Leak Proof Pulse Mold Waterway Cleaner

A: MAIN FUNCTION
1. Measure leak and pressure.
2. Automatic cleaning (One-way and two-way cleaning, electronic pulse blasting cleaning mode, cleaning time, cleaning water pressure, cleaning air pressure can be set by user), automatic blowing and drying, manual blowing and drying, more than 1000sets of cleaning records.

B: MAIN PARAMETERS
Unit Size: 740*590*620MM
Tank Size: 600*450*400MM
Tank Capacity: 108 Litre
Ultrasonic Power: 1500W
Heating Power: 3000W
Ultrasonic Frequency: 40kHz or 28kHz,or customize
Heater: Room temp.to 85℃ adjustable
Timer: 1-99 hours adjustable
